Dimensions:



Floor/Foundation:

• 6’ x 10’ (60 sq/ft) outside floor/structure perimeter dimensions.

• 2” high foundation (Estimated) depending on the slope of grade. Extra ground prep/excavations available

• 6” floor height

Walls/Structure:​

• 6 x 10' total outside wall dimensions

• 8' front wall height, 7' rear wall height

• 8' interior vault height (from sub-floor to gable roof interior vault dimensions)

• 9' total structure height (from grade to roof peak (estimated depending on grade)

Windows/Doors/Features:

• (1x) 36” x 80” single door

Roof/Soffit:

•  4\12 roof pitch (18-degree slope)

•  Single slope (lean-to) style roof

• (2x length) 10’ x 1’ front & rear lengths soffit perimeter dimensions

• (2x length) 8’ x 1’ both side widths soffit perimeter dimensions

• (1x slope) 8'6" W x 12’6” L roof outside perimeter dimensions

• 15” total side & rear roof overhang including roof-trim & shingle overhang



Materials & Design:

​

Foundation & Framing:

• Concrete pier blocks (8"W x 8"L x 8"H) and/or paver stones (12"W x 12"L x 2"H) are installed on gravel and dug into grade to create a level surface

• Weather-resistant, pressure-treated 2x6 floor joists spaced 16” on-center. Fastened with corrosion-resistant galvanized nails.

• 3" rigid styrofoam floor-joist insulation optional (select the option as an extra on our 'Get a Quote Request' Form).

• Doubled up perimeter edge beams with joist hanging hardware (acts as permanent support and extra floor weight load rating).

• Structures over 8' in width get a mid-span floor beam installed perpendicular to joists for a solid, non-deflective, rigid, floor.

• 3/4” T&G floor plywood, glued & screwed, staggered tight joints & seams.

• 2x4 wall & roof framing using 16" o/c spacing.

Siding & Exterior:

• Completely finished exterior with James Hardie Panel color-matched siding (siding, trim detail & color to match the existing house).

• Color match Hardie caulk finishes edges & seals from moisture while allowing expansion & contraction.

• Tyvec seamless water-proofing paper membrane installed on the 1/2" plywood wall sheathing.

• The exterior water-proofing envelope is fully sealed from weather, rodents, and bugs.

• Includes 3/8"x 8' weather-treated rain-screen vertically installed 16" o/c, and perforated bug-screen installed horizontally at the bottom to seal from all weather, rodents, and bugs.

• Before installation, the siding is pre-painted on-site by us.

• Grade A (Local Residential exterior style/quality) ‘Comb Face Real-Trim’ roof, and wall trim.

• Full-length window, door, wall, roof trim & siding; No seams or splices, straight lengths (material hand-picked & graded for straightness & quality)

• Soffits (underside of roof overhang) fully finished in 1x6 T&G pine, pre-painted/stained before installation.

• 2" vinyl perforated venting strip installed seamlessly into both the front & rear soffit lengths for ventilation & bug/rodent resistance.

Roof & Additional Features:

• 1/2" standard fir plywood roof sheathing.

• 60M roof felt underlay with a full double layer.

• 25-year warrantied Asphalt shingles ‘to-code’ with doubler starter layer, 8-in. Stagger, roofing sealant &
  ridge cap. Color matching to existing structure shingle color available.

• Window(s) are residential exterior grade, vinyl, dual-pane. Includes slider, screen & lock.

• 36" x 80” steel exterior-grade insulated single door.  Installed ‘to-code’ (or on-par longevity, durability, water/rain, bugs, air tightness, sealed & security) materials, installation methods & details on par or better than local residential quality & longevity standards. Includes dead-bolt/key & handle.

• 36" custom front roof overhang. Fully finished in tongue & groove pine soffit & venting strip.
